DualDrive · December 2002
12
13
14
12
MAINTENANCE AND CARE
CABLE CHANGE
CABLE CHANGE
Leave the shifter on the
handlebar.
» No need to move other components.
The shifter does not need to be
opened.
» Use only new high quality cable
(stainless) and compressionless
cable housing with end caps.
Twist shifter (rear derailleur):
» Detach the cable from the
derailleur.
» Cut cable off 15 cm (6") from
shifter barrel adjuster. Discard old
cable and cable housing.
Remove screw (1) and pull open
the cable change sleeve (2).
Rotate the shifter fully in the
cable release direction (gear
position “7/8/9“). Look for cable
head entry (3).
» Push cable up/out of the shifter
and discard.
» Feed the new cable through the
cable entry.
Pull cable snug.
Install cable change sleeve (2)
and fit screw (1).
2
1
3
4
5
12
13
12
