SRAM G2 R User Manual

13
Caliper Piston Removal
Install the pad retention bolt.Install the pad retention bolt.
Insert the pad spacer so that it snaps onto the pad retention bolt.Insert the pad spacer so that it snaps onto the pad retention bolt.
Squeeze the brake lever to advance the pistons until they contact the Squeeze the brake lever to advance the pistons until they contact the
pad spacer. pad spacer.
Remove the pad spacer.Remove the pad spacer.
Remove the pad retention bolt.Remove the pad retention bolt.
3
2.5 mm 1.85 mm pad spacer
4
5
2.5 mm
