14
Caliper Piston Removal
Pull the rubber boot from the compression nut.Pull the rubber boot from the compression nut.
Disconnect the brake hose from the caliper body.Disconnect the brake hose from the caliper body.
Remove each caliper body bolt.Remove each caliper body bolt.
Separate the caliper body halves. Separate the caliper body halves.
6
7
8 mm flare nut wrench
8
T25
9
