SRAM G2 R User Manual

15
Caliper Piston Removal
Remove both of the caliper o-rings from the inboard side of the caliper.Remove both of the caliper o-rings from the inboard side of the caliper.
Remove the pistons from each caliper body half.Remove the pistons from each caliper body half.
NOTICE
If it is not possible to remove the pistions by hand, soft-jawed pliers
may be used to carefully remove the pistons.
Remove the piston seals from each caliper body half. Install new seals Remove the piston seals from each caliper body half. Install new seals
inside each caliper body half.inside each caliper body half.
⚠ WARNING
Do not scratch the seal gland with the pick. Scratches could cause
fluid to leak when the brake is applied, which will contaminate the
brake pads and could lead to a brake failure.
NOTICE
Do not apply grease to the caliper piston seals. Grease on the seals
will reduce the clearance between the pads and rotors when the
brake is released (low pad rollback).
10
11
12
Pick
