Solo Air Spring Service
Remove the inner o-rings on the air shaft stud. Remove the inner o-rings on the air shaft stud.
Clean the air shaft stud. Clean the air shaft stud.
Apply grease and install a new o-ring.Apply grease and install a new o-ring.
Remove the o-ring from the split keeper. Remove the split keeper from Remove the o-ring from the split keeper. Remove the split keeper from
the air shaft.the air shaft.
Remove the top out bottom-out platform, bottom out bumper, retaining Remove the top out bottom-out platform, bottom out bumper, retaining
ring, and seal headring, and seal head from the air shaft.from the air shaft.
Clean and inspect the shaft for damage.Clean and inspect the shaft for damage.
NOTICE
Scratches on the air spring shaft can cause air to leak. If a scratch is
visible the air spring assembly may need to be replaced.
Remove the outer and inner o-rings on the seal head. Remove the outer and inner o-rings on the seal head.
Clean the seal head. Clean the seal head.
Apply grease and install new o-rings.Apply grease and install new o-rings.
