SRAM ROCKSHOX RUDY XPLR User Manual

28
Bleed Procedure
Install the bleed screw. Install the bleed screw.
Rapidly push the rebound shaft in and out 15-20 times. Rapidly push the rebound shaft in and out 15-20 times.
Compress the damper in a vertical position for five minutes. This will Compress the damper in a vertical position for five minutes. This will
allow the remaining bubbles to float to the top. allow the remaining bubbles to float to the top.
Extend the rebound shaft. Extend the rebound shaft.
Remove the bleed screw. Thread a half full syringe into the bleed port.Remove the bleed screw. Thread a half full syringe into the bleed port.
⚠ CAUTION  EYE HAZARD
Oil will eject from the damper assembly if the rebound shaft is
compressed. Wear safety glasses.
T10
11
12
13
14
T10
