Srne ML Series User Manual

20℃
50℃
70℃
60℃
40℃
30℃
太
阳
板
温
度
I(A)
U(V)
温度降低，电流不变，
功率增大
温度升高，开路电压减小
Figure 1-4 Solar Panel Output Characteristic and Temperature Relation
1.4 Introduction of Charging Stages
As a stage of charging, MPPT cannot be used separately, but must be combined
with charging modes such as boost charging, floating charging and equalizing
charging to complete battery charging together. A complete charging process
includes: fast charging, maintaining charging and floating charging. The charging
curve is as follows:
Temperature reduces, current remains constant,
and power increases
S
o
l
a
r
p
a
n
e
l
t
e
m
p
e
r
a
t
u
r
e
Temperature increases and open circuit voltage reduces
