3–22 INSTRUMENTS AND CONTROLS
1. It indicates 16-direction by intervals of
22.5° according to the vehicle’s driving
direction.
• When the first equipped to the vehicle
or the battery is exchanged, you have
to perform calibration by circulating your
vehicle. If not, there will be misreading
in direction.
Turning calibration
1. If you press the adjustment switch for
0.5~5 seconds, the current direction
flashes.
2. Turn the vehicle over 1 complete circle
within 128 seconds slowly, then the
calibration will be accomplished.
3. When the calibration is finished, the
vehicle’s new direction will be indicated.
Electronic Compass
NOTE
The direction will be indicated while
driving.
NOTE
•
You can turn to any direction, left
or right.
•
When the calibration is completed,
the compass does not flash
anymore.
•
If the compass continues to flash,
turn again slowly until it goes off.
