ST STM32F101 series User Manual

UM0462 Getting started
5/14
Figure 1. System Properties dialog box
For the communication, you need to verify that you have an available COM port(RS232) as
one COM port is required for system connection.
To check that you have an available communication port, right-click on the “My Computer”
icon on the desktop and select “Properties” from the pop-up menu. The “System Properties”
dialog box appears. Click on the “Hardware” tab, and then on the “Device manager” button
to display the system hardware configuration. Available COM ports are grouped under the
”Ports (COM & LPT)” node in the hardware tree as shown in Figure 2.

ST STM32F101 series Specifications

General

Series	STM32F101
Core	ARM Cortex-M3
Flash Memory	16 KB to 128 KB
GPIO Pins	Up to 80
Operating Voltage	2.0 V to 3.6 V
Operating Temperature	-40°C to +85°C
Communication Interfaces	I2C, SPI, USART
Package	LQFP

Summary

Introduction to Flash Loader Demonstrator

Getting Started with STM32 Flash Loader

Package Contents Overview

Lists the software and hardware components provided with the Flash loader demonstrator.

System Requirements for Operation

Details the necessary PC hardware and operating system for using the demonstrator.

Flash Loader Demonstrator Installation Guide

Step-by-step instructions for installing the Flash loader demonstrator software and hardware.

STM32 Flash Loader User Interface Walkthrough

Welcome Window and Initial Steps

Describes the initial welcome screen and how to start the demonstrator wizard.

Configuring Connection Settings

Explains how to set up UART parameters for establishing communication with the target device.

Viewing Device Information

Details how to view target ID, read protection status, and flash memory mapping.

Selecting Operation Type

Guides users on choosing between erase, download, and upload operations and their parameters.

Monitoring Operation Progress

Shows how to track the progress, success, or failure of data operations.
