5 Quick start
The STM32G0 Nucleo-32 board is a low-cost and easy-to-use development kit, used to evaluate and start a
development quickly with an STM32G0 Series microcontroller in LFQFP 32-pin package. Before installing and
using the product, accept the Evaluation Product License Agreement from the www.st.com/epla webpage. For
more information on the STM32G0 Nucleo-32 and for demonstration software, visit the www.st.com/stm32nucleo
webpage.
5.1 Getting started
Follow the sequence below to configure the STM32G0 Nucleo-32 board and launch the demonstration application
(refer to Figure 4 for component location):
1. Check the jumper position on the board (refer to Table 4)
2. For the correct identification of the device interfaces from the host PC and before connecting the board,
install the ST-LINK/V2-1 USB driver available on the www.st.com website
3. To power the board, connect the STM32G0 Nucleo-32 board to a PC with a USB cable (Type-A to Micro-B)
through the USB connector CN1 of the board
4. Then, red LED LD1 (COM) and green LED LD2 (5V_PWR) light up, green LED LD3 blinks
5. Remove the jumper placed between D2 (CN3 pin 5) and GND (CN3 pin 4)
6. Observe how the blinking of the green LED LD3 changes, when the jumper is in place or removed
7. Download the demonstration software and several software examples that help to use the STM32 Nucleo
features. These are available on the NUCLEO-G031K8 webpage
8. Develop your own application using the available examples
Table 4. Jumper configuration
Jumper
Definition
Position
(1)
Comment
(1)
JP1 IDD ON For STM32G0 current measurement
1. Default jumper state is shown in bold.
UM2591
Quick start
UM2591 - Rev 1
page 6/26
