Figure 11. ARDUINO
®
connectors
CN4
ARDUINO
®
Nano
connector
CN3
ARDUINO
®
Nano
connector
The related pinout for ARDUINO
®
connector appears in Figure 12 and is listed in Table 11.
UM2397
ARDUINO® Nano V3 connectors
UM2397 - Rev 2
page 20/30
