ST STM32L152-EVAL User Manual

December 2010 Doc ID 18141 Rev 1 1/44
UM1018
User Manual
STM32L152-EVAL evaluation board
Introduction
The STM32L152-EVAL evaluation board is a complete demonstration and development
platform for STMicroelectronics’ ARM cortex-M3 core-based STM32L152VBT6
microcontroller supporting two I2C, two SPI and three USART channels, 12-bit ADC, 12-bit
DAC, 16 KB internal SRAM and 128 KB Flash, USB FS, LCD controller, touch sensing and
JTAG debugging support.
The full range of hardware features on the board helps you evaluate all peripherals (USB
FS, USART, Audio DAC, microphone ADC, dot-matrix LCD, LCD glass, IrDA, light
dependant resistor (LDR), MicroSD Card
TM
and temperature sensor amongst others) and
develop your own applications. Extension headers make it possible to easily connect a
daughter board or wrapping board for your specific application.
An ST-LINK/V2 is integrated on the board as embedded in-circuit debugger and
programmer for the STM32 MCU.
www.st.com
Downloaded from Elcodis.com electronic components distributor

ST STM32L152-EVAL Specifications

General

Core	ARM Cortex-M3
Operating Frequency	Up to 32 MHz
Flash Memory	128 KB
I/O Ports	Yes
GPIO Pins	Up to 51
ADC	12-bit
ADC Channels	Up to 16
DAC Channels	2
Communication Interfaces	I2C, SPI, USART
USB	USB 2.0 full-speed
Connectors	USB
On-board Features	LEDs, buttons, joystick
LCD Driver	Yes
Operating Temperature	-40°C to +85°C

Summary

Hardware and Layout

Development and Debug Support

Embedded ST-LINK/V2 for on-board program loading and debugging via JTAG or SWD.

Power Supply

Details on powering the board via various sources and associated LEDs.

Clock Source

Information on the two available clock sources: 32 KHz crystal and 8 MHz crystal.

Reset Source

Lists the various sources that can trigger a reset on the evaluation board.

IDD Measurement

Built-in circuit for measuring MCU current consumption in Run or Low power modes.

Connectors

ST-LINK/V2 USB Type B Connector CN11

USB connector for connecting the embedded ST-LINK/V2 to a PC for debugging.

User USB Type B Connector CN1

USB connector for user interaction and potentially powering the board.

JTAG Connector CN9

Connector for JTAG debugging interface.

Trace Debugging Connector CN8

Connector for trace debugging functionality.
