Schematics UM1018
28/44 Doc ID 18141 Rev 1
4 Schematics
The following schematics are listed.
● Figure 13: STM32L152-EVAL on page 29
● Figure 14: MCU on page 30
● Figure 15: LCD glass on page 31
● Figure 16: Audio on page 32
● Figure 17: Peripherals on page 33
● Figure 18: Power on page 34
● Figure 19: Extension connector on page 35
● Figure 20: LCD and SD Card on page 36
● Figure 21: RS-232 and IrDA on page 37
● Figure 22: IDD_Measurement on page 38
● Figure 23: Temperature sensor on page 39
● Figure 24: ST-LINK on page 40
● Figure 23: Temperature sensor on page 39
● Figure 26: Touch sensing on page 42
