UM1018 Connectors
Doc ID 18141 Rev 1 23/44
3.5 ST-LINK/V2 programming connector CN10
Connector CN10 is used only for embedded ST-LINK/V2 programming during board
manufacture. It is not populated by default and is not for end user usage.
4 PD13 LCD glass_SEG33 Remove LCD glass U20
6 PD11 LCD glass_SEG31 Remove LCD glass U20
8 PD9 LCD glass_SEG29 Remove LCD glass U20
10 GND - -
12 PD8 LCD glass_SEG28 Remove LCD glass U20
14 PB14 uSD_SPI2_ -
16 PB12 POT_ADC18 JP17 open
18 PB10 LCD glass_SEG10 Remove LCD glass U20
20 PE15 LCD_SPI1_MOSI -
22 PE13 LCD_SPI1_SCK -
24 PH1 OSC_OUT Remove X2 from socket and close SB2
26 PE11 JOYSTICK_RIGHT Remove R117
28 PE9 JOYSTICK_UP Remove R126
30 GND - -
32 PB2 BOOT1 / TS_LOAD -
34 PB0 LCD glass_SEG5 Remove LCD glass U20
36 PC4 LCD glass_SEG22 Remove LCD glass U20
38 PA6 LCD glass_SEG3 Remove LCD glass U20
40 PA5 BNC JP14 open
42 PA3 LCD glass_SEG2 Remove LCD glass U20
44 PA1 LCD glass_SEG0 Remove LCD glass U20
46 PC2 LCD glass_SEG20 Remove LCD glass U20
48 PC0 LCD glass_SEG18 Remove LCD glass U20
50 GND - -
Table 16. Daughterboard extension connector CN7 (continued)
Pin Description Alternative function
How to disconnect with function block
on STM32L152-EVAL board
