The STM32H7 Nucleo-144 boards offer the following features:
• STM32H7 Arm
®(a)
Cortex
®
core-based microcontroller in LQFP144 package
• Ethernet compliant with IEEE-802.3-2002 (depending on STM32H7 support)
• USB OTG full-speed
• 3 user LEDs
• 2 push-buttons: USER and RESET
• LSE crystal:
– 32.768 kHz crystal oscillator
• Board connectors:
– USB with Micro-AB
– Ethernet RJ45
–MIPI10
• Board expansion connectors:
– ST Zio including ARDUINO
®
Uno V3
–ST morpho
• Flexible power-supply options: ST-LINK USB V
BUS
or external sources
• On-board STLINK-V3 debugger/programmer with SWD connector:
– USB re-enumeration capability: virtual COM port, mass storage, debug port
– STLINK-V3 standalone kit capability
• Comprehensive free software libraries and examples available with the STM32Cube
package
• Support of a wide choice of Integrated Development Environments (IDEs) including
IAR Embedded Workbench
®
, MDK-ARM, and STM32CubeIDE
