UM2411 Rev 2 57/61
UM2411 STM32H747I-DISCO I/O assignment
60
P3 PH4 ULPI_NXT
P4 PH5 FMC_SDNWE
P5 PI15 LED4
P6 PJ1 OTG_HS_OverCurrent
P7 PF13 FMC_A7
P8 PF14 FMC_A8
P9 PE9 FMC_D6
R1 PC2_C ARD_A4
R10 PE12 FMC_D9
R11 PE15 FMC_D12
R12 PJ5 ARD_D8
R13 PH9 FMC_D17
R14 PH12 FMC_D20
R15 PD11 QSPI_BK1_IO0
R16 PD12 PMOD#7/ARD_D15-I2C4_SCL
R17 PD13 PMOD#10/ARD_D14-I2C4_SDA
R2 PC3_C ARD_A5
R3 PA6 ARD_D5-TIM3_CH1 || DCMI_PIXCLK
R4 VSS -
R5 PA7 ETH_/RX_DV/CRS_DV/SYNC
R6 PB2 QSPI_CLK
R7 PF12 FMC_A6
R8 VSS -
R9 PF15 FMC_A9
T1 PA0_C ARD_A2
T10 PE13 FMC_D10
T11 PH6 FMC_SDNE1
T12 VSS -
T13 PH8 FMC_D16
T14 PB12 ULPI_D5
T15 PB15 PMOD#8-SPI2_MOSI/2_SDO
T16 PD10 FMC_D15
T17 PD9 FMC_D14
T2 PA1_C ARD_A3
T3 PA5 ULPI_CK
Table 21. STM32H747I-DISCO I/O assignment (continued)
Pin GPIO port GPIO primary interface
