STM32H747I-DISCO I/O assignment UM2411
56/61 UM2411 Rev 2
M14 PJ9 ARD_D0-UART8_RX
M15 VSSDSI -
M16 DSI_D0P -
M17 DSI_D0N -
M2 PC1 ETH_MDC || SAI4_D1
M3 PC2 PMOD#3-SPI2_MISO/2_SDI
M4 PC3 PMOD#2-SPI2_MOSI/2_SDO
M5 VDD -
N1 VREF- -
N10 VDD -
N11 VDD -
N12 VDD -
N13 PJ8 ARD_D1-UART8_TX
N14 PJ7 ARD_D6-TIM8_CH2N
N15 PJ6 ARD_D9-TIM8_CH2
N16 VSS -
N17 VCAPDSI -
N2 PH2 QSPI_BK2_IO0
N3 PA2 ETH_MDIO
N4 PA1 ETH_/RX_CLK/REF_CLK/CLK
N5 PA0 PMOD#1- USART2_CTS_NSS
N6 PJ0 ARD_D7
N7 VDD -
N8 VDD -
N9 PE10 FMC_D7
P1 VSSA -
P10 PE11 FMC_D8
P11 PB10 ULPI_D3
P12 PB11 ULPI_D4
P13 PH10 FMC_D18
P14 PH11 FMC_D19
P15 PD15 FMC_D1
P16 PD14 FMC_D0
P17 VDDDSI -
P2 PH3 QSPI_BK2_IO1
Table 21. STM32H747I-DISCO I/O assignment (continued)
Pin GPIO port GPIO primary interface
