UM2411 Rev 2 55/61
UM2411 STM32H747I-DISCO I/O assignment
60
J7 VSS -
J8 VSS -
J9 VSS -
K1 NRST NRST
K10 VSS -
K11 VSS -
K13 VDD -
K14 PJ11 ARD_D12-SPI5_MISO
K15 VSSDSI -
K16 DSI_D1P -
K17 DSI_D1N -
K2 PF6 QSPI_BK1_IO3
K3 PF7 QSPI_BK1_IO2
K4 PF8 PMOD#14_PWM || ARD_D3-TIM13_CH1
K5 VDD -
K7 VSS -
K8 VSS -
K9 VSS -
L1 VDDA -
L10 VSS -
L11 VSS -
L13 VDD -
L14 PJ10 ARD_D11-SPI5_MOSI || TIM1_CH2N
L15 VSSDSI -
L16 DSI_CKP -
L17 DSI_CKN -
L2 PC0 ULPI_STP
L3 PF10 ARD_A1
L4 PF9 QSPI_BK1_IO1
L5 VDD -
L7 VSS -
L8 VSS -
L9 VSS -
M1 VREF+ -
M13 VDD -
Table 21. STM32H747I-DISCO I/O assignment (continued)
Pin GPIO port GPIO primary interface
