Stabila LD420 - Pythagoras 1; Pythagoras 2 (3-Point)

Stabila LD420
Special Functions
10
EN
Pythagoras 1
1
2
Aim laser at up-
per point.
3
4
Aim laser rectan-
gular at lower
point.
i.479 m
4.379 m
4.622 m
i8.66 °
5
i
The result is shown
in the main line and
the measured dis-
tances above.
Pressing the meas-
uring key for 2 sec
in the function acti-
vates automatically
Minimum or Maxi-
mum measure-
ment.
Pythagoras 2 (3-point)
1
2
Aim laser at up-
per point.
3
4
Aim laser at rec-
tangular point.
5
6
Aim laser at lower point.
2.52i m
4.004 m
3.936 m
4.322 m
7
i
The result is shown in the main
line and the measured distances
above.
Pressing the measuring key for
2 sec in the function activates
automatically Minimum or Maxi-
mum measurement.
With the MENU key additional
results can be selected.
i.787 m
24.42 °
8
0.734 m
i0.56 °
9
2x
