Save This Manual for Future Reference
Original Instruction
PREFACE
Thank you for choosing the gasoline generator set of our company.
Based on the latest technology at home and abroad, our Company. has successfully developed
the gasoline generator set. The unit is characterized by advanced design, compact structure,
reliable performance, convenient service, low fuel consumption and noise as well as fashionable
shape. With general gasoline engine as power, it is widely used in many fields such as daily life,
fishing, open working, power generation for bank , shop or restaurant, and so on.
The manual gives information with respect to operation and maintenance of the gasoline
generator. Please read it carefully first before operating. If any trouble occurs, ask your local dealer
who will provide you with the best after service.
All the materials and diagrams of this manual coincide with the newest products at the publishing
time. Due to revision and other changes, the information descried in this manual may be a little
different from the actual status. The copyright of this manual belongs to our Company. any group
or individual is forbidden to reprint or copy any it. The manual is subject to change without notice.
IMPORTANT NOTICES
Please pay special attention to statements preceded by the following words:
WARNING:
A warning is used to alert the user to fact that hazardous operating and maintenance
procedures may result in injury to or death of personnel if not strictly observed.
CAUTION:
A caution is used to alert the user to fact that hazardous operation and maintenance
procedures may result in injury to or death of personnel if not strictly observed.
NOTE: Give helpful information.
This manual should be considered as a permanent part of the unit and should remain with the unit
when resold.
CONTENTS
1. Specifications ………………………………………………………………….………………...…………..………..
2. Generator Safety………………………………………………………………………………………...…………….
3. Introduction to Parts and Components ……………………….……..……………………………..………………
4. Pre-operation Inspection ……………………………………………………………..………………………...……
5. Starting the Engine…………………………………………………………………………...………….……………
6. Automatic transfer switch (ATS) …………………………………………………………...………………………..
7. Service…………………………………………………………………………………………..….……….…………
8. Stopping the Engine ……………………………………………….…………………………...………………….…
9. Maintenance ………………………………………………………………………………………...….……………..
10. Storage ……………………………………………………………………………………..………………………...
11. Troubleshooting……………………………………………………………………………..…………………..……
12. Assembly of parts……………………………………………………………………………..……………….…….
13. Wiring Diagram ………………………………………………………………………………..………………..…...
30
32
33
34
36
38
41
43
44
46
47
48
49
