Stager FD Series - Specifications

1. SPECIFICATION
Model FD2500 /
FD2500E
FD3000 /
FD3000E /
FD3000E-ATS*
FD3600E /
FD3600E+ATS*
FD4000E FD6500E /
FD6500E+
ATS*
FD7500E /
FD7500E+ATS
*
Engine
Model YH168FB(E) YH168FB YH170F(E) YH170F(E) YH188F(E) YH190F(E)
Type Gasoline engine, 4-stroke, single cylinder, OHV, forced air-cooled
Rated power (HP) 6.5 6.5 7.5 7.5 13 16
Rated speed (rpm) 3000 / 3600
Displacement (cm³) 196 196 208 208 389 420
Engine oil capacity (L) 0.6 0.6 0.6 0.6 1.1 1.1
Engine oil type SAE10W-40, 15W-40
Fuel type Gasoline
Fuel tank capacity (L) 10 10 10 10 22
Voltage adjust type AVR
Ignition system CDI
Generator
Rated voltage (V) ~ 230 ~ 230 ~ 230 ~ 230 ~ 230 ~ 230
Rated frequency (Hz) 50 50 50 50 50 50
Rated power (kW) 2.0 2.5 2.8 3.3 5.0 6.0
Maximum power (kW) 2.2 2.8 3.0 3.6 5.5 6.5
Rated current (A) 8.7 10.9 12.17 14.35 21.74 26.09
Power factor 1.0
Dimensions (mm)
615 x 450 x
485
615 x 450 x 485 615 x 450 x 485 615 x 450 x 485 720 x 540 x 595 720 x 540 x 595
Noiese level LwA (dB) 93 93 93 93 96
Protection grade IP23M
Starting system Recoil / E: electric
Autonomy (hours) 8 8 6 7 8 6.5
Net / gross weight (kg) 46/49 41/44; E: 46/49 49 / 52 52 / 55 86 / 90 90 / 94
Model FD9500E FD10000E /
FD10000E+ATS*
FD7500E3 FD10000E3 /
FD10000E3+ATS*
Engine
Model YH192F(E) YH192FB(E) YH190F(E) YH192FB(E)
Type Gasoline engine, 4-stroke, single cylinder, OHV, forced air-cooled
Rated power (HP) 17.5 19 16 19
Rated speed (rpm) 3000 / 3600
Displacement (cm³) 439 459 420 459
Engine oil capacity (L) 1.2 1.2 1.1 1.2
Engine oil type SAE10W-40, 15W-40
Fuel type Gasoline
Fuel tank capacity (L) 22
Voltage adjust type AVR
Ignition system CDI
Generator
Rated voltage (V) ~ 230 ~ 230 ~ 230/400 ~ 230/400
Rated frequency (Hz) 50 50 50 50
Rated power (kW) 7.0 8.0 6.0 8.0
Maximum power (kW) 7.5 8.5 6.5 8.5
Rated current (A) 30.43 34.78 10.84 14.5
Ver. 3/Rev. 1; Data: 21.10.2022 30
