4.2 FUEL LEVEL
1. Open the fuel filler cap. 3. Check the fuel level, and fill fuel if necessary.
2. Fill fuel to the shoulder of the filter. 4. Reinstall the fuel filler cap well.
4.3 AIR CLEANER
1. Remove the clip and dismantle the air housing
2. Check and make sure the air cleaner core is intact
and clean. If it is broke, replace it with a new one.
4. Put the filter element in to the original position,
install the cover and secure it well.
3. If the core is filthy, clean it in the following
sequence.
a) Clean the core in the cleansing solvent.
b) Dry it up
c) Dip a few drops of engine oil into it.
d) Squeeze excess oil
4.4 BATTERY
Check and make sure that the electrolyte level of each
battery cell is between is upper and lower level marks.
1. upper level mark
2. lower lever mark
Ver. 3/Rev. 1; Data: 21.10.2022 35
