7.2. The following table gives reference information for connection the electric appliances to
generator.
Description
Wattage
Typified
Example
Start Rating Electric device Start Rating
- Incandescent
lamp
- Heating
device
×1 ×1
Incandescent
lamp
TV
Incandescent
lamp
100W
100VA
(W)
100VA
(W)
- Fluorescent
lamp ×2 ×1.5
Fluorescent lamp
Fluorescent
lamp
40W
80VA
(W)
60VA
(W)
- Motor drive
device
×3~
5
×2
Refrigerator
Electric fan
Refrigerator
150W
450~750VA
(W)
300VA
(W)
7.3. If the generator is to supply two or
above loads with power supply, be sure to
connect them one by one with higher start
current first.
7.4 Connecting methods illustrated as follows.
a) Correct b) Forbidden
Ver. 3/Rev. 1; Data: 21.10.2022 42
