8. Specifications
Output Specifications
Output
Voltage
Range
Versions:
+/-100mV
+/-1V
+/-5V
+/-10V
+/-14V
depending on version: single fixed range +/-100mV to +/-14V, bipolar
Note, that approx. 1V of overrange is provided in some devices, e.g. a +/-14V
device actually delivers (at low output current) up to +/-15V
Number of Outputs
1, 2, 4, 8, 10, 12 or 16 output lines, depending on device configuration
Output Connectors
BNC sockets (standard), SubD 25pole female, others on request
Output
Current
per output
approx. +/-10mA
(4-quadrant operation, U
OUT
 < 10mA)
Overload-indication above +/-8.6mA
Output
Reference Ground
All outputs share a common GND, which can be floated up to +/-100V vs.
case ground.
Output resistance
50 Ohm +/-3% , at I < 2mA, versions +/-5V to +/-14V
2 Ohm +/-15% , at I < 6mA, version +/-100mV
Programming Resolution
BS series: 16 Bits
BSA series: 19 Bits
Accuracy
typical error maximum error typical drift
% of Setting 0.014% 0.02% 0.001% per day
Offset error
Version +/-5V to +/-14V
+/-1V
+/-100mV
±0.9mV
±0.45mV
±15µV
±1.8mV
±0.9mV
±50µV
±0.05mV per day
±0.01mV per day
±4µV per day
Temperature drift
Version +/-1V to +/-14V
related to Span
related to Offset
Version +/-100mV
related to Span
related to Offset
BS: 5ppm/K
BSA: 2.5ppm/K
15µV/K
20ppm/K
4µV/K
Output Fluctuations
typical maximum conditions
Ripple (50Hz, 100Hz)
Version +/-5V to +/-14V
Version +/-100mV
BS: < 28µV rms
BSA: < 8µV rms
< 2.4µV rms
36µV rms
17µV rms
7µV rms
no output current
no output current
no output current
Noise, 10kHz…10MHz
Version +/-5V to +/-14V
Version +/-100mV
 0.5mV rms
 0.06mV rms
Short/Mid Term Fluctuations
@ output voltage 10V, any
channel vs. GND, Version ±10V
Short Term
1 day
Version ±100mV
Output at 100mV, Short Term
1 day
Offset 1 day
BS: 21µV pp
BSA: 8µV pp
80µV pp
0.9µV pp
20µV pp
4µV pp
BS: 45µV pp
BSA: 20µV pp
150µV pp
-sampling interval 1s-
observation period 100s
observation period 100s
observation period 24h
observation period 100s
observation period 24h
observation period 24h
