Stahl SLE 3 - Motor management table

3 Product and functional description
14 06.2017
BA_SLE3_EN.DOCX
Motor management table
This table shows the relationship between the settings and times:
Motor type
S1
S3
ts
[ms]
tf
[ms]
tr
[ms]
ta
[ms]
tb
[ms]
Unknown
0
600
1250
1250
500
500
12/2H33
1
250
500
500
0
250
12/2H42
2
250
500
500
0
250
12/2H62
3
250
500
500
0
250
12/2H71
4
400
750
750
300
300
12/2H72
5
400
750
750
300
300
12/2H73
6
400
750
750
400
400
12/2H91
12/2H92
7
600
1250
1250
500
500
Ex-Motor
A-xxx
A
400
750
750
0
0
Frequency-
controlled
F
0
0
0
0
0
Motor management parameters for motors from Stahl CraneSystems and third-party motors
– F = Setting for operation with a frequency inverter
– In setting 8 … E, the highest setting, as in item 7, is retained.
Operation with frequency inverter
When working with a frequency inverter, the switch S1 is set to "F" and the switch S3_1
to "on".
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
