ASSEMBLY INSTRUCTIONS
8
NOTE: Lay your partially assembled 1205 PRECISION ROWER upside down to complete Steps 3 and
4.
STEP 3
Place the LEFT and RIGHT BASE FRAMES(2, 3) on the CENTER BEAM(1), connect them with the two
MOUNTING BRACKETS(4), and secure with HEX BOLTS (M8x1.25x16mm)(28) and LOCK WASHERS(M8)
(35).
STEP 4
Attach the REAR STABILIZER(12) to the CENTER BEAM(1) with HEX BOLTS(M8x1.25x60mm)(31),
WASHERS(M8)(37), and LOCK WASHERS(M8)(35).
