Stanley Dura-Glide 2000AG Series - Installing the SX Panel(s)

203729
Rev. E, 11/20/18
© 2018, THE STANLEY WORKS. ALL RIGHTS RESERVED. 7 of 18
3.6 Installing the SX Panel(s)
3.6.1 Refer to Section 3.2, and INSTALL top and bottom rails onto SX panel glass.
3.6.2 Figure 4, and INSTALL the Door holder assembly as follows:
a. Using the supplied ¼″-20 X 2″ socket head capscrews and tapped holes, SECURE
damper assembly to top rail of door panel.
b. Using the supplied ¼″-20 X 1″ socket head capscrews, SECURE door holder
assembly to header.
3.6.3 Refer to Figure 5, and LOOSEN the nuts securing the load wheels and anti-riser
wheels to the hanger.
Figure 4. Installing the Door Holder Assembly
