© 2005, THE STANLEY WORKS. ALL RIGHTS RESERVED.
204027
Rev. C, 11/9/05
19 of 31
Table 5. Magic Force/Magic Swing Configuration Codes—Motor 2
Defaults
Index Min. Value Max. Value Description
Low Energy Full Energy
20 05 35 Open speed, revolutions per second 09 20
21 03 12 Check speed, revolutions per second 04 04
22 05 40 Stall speed, percent of PWM counts N/A N/A
23 00 99 Open check length, percent of full opening N/A N/A
24 00 99 Magic Touch sensitivity (00 = OFF, 01-99 =
sensitivity) (01 = max. sensitivity)
00 00
25 00 99 Magic Touch hold open time (25 sec. max. =
99%)
21 15
26 00 99 Hold-open delay in % (25 sec. max. = 99%) 21 05
27 05 99 Open torque, percent of full torque 33 33
28 05 99 Check torque, percent of full torque 23 23
29 05 99 Stall torque, percent of full torque 23 23
30 Reserved NA NA
31 Reserved NA NA
32 Reserved NA NA
33 00 99 Obstruction time in % (2.5 sec. max. = 99%) 19 19
34 00 60 Open Acceleration Slope 07 07
35 00 99 Open Braking Slope 15 40
36 Reserved NA NA
37 Reserved NA NA
Table 6. Status Codes
Status Code Description
00 Normal operation—All OK
20 Breakout
55 Stall state
A0 First installation sequence (FIS)
A1 Auto-configuration sequence
A2 Auto-configuration confirmation sequence
b0 Invalid mode
b1 Encoder error
dc Display door cycle counter
EE Obstruction in Learn Mode
0b Obstruction after Learn Mode
