Stanley ProSert XTN20 - Specification; Placing Tool Specification

Items with a * may require a mandrel adaptor kit (74202-02200 found in Accessories Manual 07900-01073). A complete ProSert®
XTN20 (74202) tool is made up of the base tool (part number 74202-02000) and the appropriate nose assembly for the insert.
2. Specication
The ProSert® XTN20 hydro-pneumatic tool is designed for placing STANLEY Engineered Fastening Blind Rivet
Nuts through adjustment of the force and/or the stroke.
The ProSert® XTN20 Tool is used to place Blind Rivet Nuts from a range of M3 to M10 when coupled with the
relevant nose equipment. Imperial nose equipment is also available to place UNC and UNF inch thread size
Blind Rivet Nuts
The safety instructions must be followed at all times.
2.1. Placing Tool Specication
Pull Force: Pull @ stated pull pressure 5.0 bar 17.65 kN 3968 lbf
Air Supply Pressure: Min/Max 5-7 bar 72.5-101.5 lbf/in
2
Oil Pressure: Pull (max) 230 bar 3336 lbf/in
2
Free Air Volume: Max @ 5.5 bar 4 ltr 244 in³
Stroke: Piston stroke 3-7 mm 0.118-0.275 in
Weight: Including nose equipment 1.59 kg 3.50 lb
Noise Level: Uncertainty noise : K=3dB(A) <75 dB(A) <75 dB(A)
Vibration: Uncertainty vibration K=0.1 m/s² <2.5 m/s
2
<8 ft/s
2
Motor Speed: Forward & Reverse 2000rpm 2000rpm
Additional Features:
Pull-to-Force operating mode Yes
Pull-to-Stroke operating mode Yes
Auto Spin On/Spin O Yes
Tool Free Mandrel ttings Yes
Manual Reverse override Yes
Hydraulic Lip Seals & O-rings Yes
Material: - Aluminium Steel Stainless Steel
Avdel® Product
Range:
Eurosert® - M3-M10 M4-M5
Thin Sheet Nutsert® M3-M10 M3-M10 M3-M10
DK/DL M4-M10 -
Euro Hexsert®/Hexsert® - M3-M8 M6
High Strength Hexsert® - M6-M8 -
Squaresert® - M5-M8 -
POP Nut®
Product Range:
Standard Nut* M3-M10 M3-M8 M4-M6
Knurled Nut* M4-M8 M4-M6 -
Closed End Nut* M3-M10 M3-M8 M4-M6
Hexagonal Nut* M4-M8 M4-M8 M4-M6
Tetra Nut* M4-M8 M4-M8 -
HB Bolt* M6-M8 M6-M8 -
Pipe Nut* M6 M6 -
