Stanley ProSert XTN20 Service Manual

2.3. Main components list
Part Nr. Desctription
Thread
Re-order
Spare part numbers
QTY
A Mandrel
M4 07555-09004 1
M5 07555-09005 1
M6 07555-09006 1
M8 07555-09008 1
B Nose Tip
M4 07555-00904 1
M5 07555-00905 1
M6 07555-00906 1
M8 07555-00908 1
C Lock Nut - 07555-00901 1
13 Nose Casing - 74202-02021 1
14 Chuck Nut - 74202-02022 1
D Reducing Sleeve
M4 07555-09104 1
M5 07555-09105 1
M6 07555-09106 1
M8 07555-09108 1
E Drive Shaft
M4 07555-01004 1
M5 07555-01005 1
M6 07555-01006 1
M8 07555-01008 1
15 Mandrel Adaptor - 74202-02023 1
73 Nose Rod - 74202-02039 1
46 Suspension Ring - 74202-02012 1
20 A,B,C End Cap Assembly - 74202-02107 1
F Stroke Indication Markings - - -
80 Stroke Locking Pin - 74202-02095 1
19 Stroke Setter - 74202-02010 1
I Stroke Setter Recess - - -
75 Air Inlet Assembly - 74202-02103 1
22 Manual Reverse Trigger - 74202-02030 1
31 Regulator Lock - 74202-02038 1
30 Pressure Regulator - 74202-02037 1
12 Trigger - 74202-02020 1
K Pin Punch - 07900-00624 1
Complete nose assembly
M4 07555-09884
M5 07555-09885
M6 07555-09886
M8 07555-09888
All sizes are supplied with Lock Nut (c) 07555-00901.
For additional sizes please visit www.StanleyEngineeredFastening.com
12
ENGLISH
