DISTRIBUTOR ASSEMBLY 74202-02105

POSITION PART NUMBER DESCRIPTION QTY SPARES

21A 74202-02011 DISTRIBUTOR 1 -

21B 74202-02093 PIN 1 -

21C 74202-02066 O RING 2 -

21D 74202-02064 O RING 2 -

21E 74202-02063 O RING 1 -

21F 07001-0047 M4 GRUB SCREW 2 -

AIR PISTON ASSEMBLY 74202-02106

POSITION PART NUMBER DESCRIPTION QTY SPARES

3A 74202-02003 AIR PISTON 1 -

3B 74202-02015 PISTON ROD 1 -

3C 74202-02069 O RING 1 1

3D 07003-00029 O RING 3 3

END CAP ASSEMBLY 74202-02107

POSITION PART NUMBER DESCRIPTION QTY SPARES

20A 74202-02008 END CAP 1 -

20B 74202-02027 SLIDER 1 -

20C 74202-02092 END CAP STOPPER 1 -

AIR INLET ASSEMBLY 74202-02103

POSITION PART NUMBER DESCRIPTION QTY SPARES

74A 74202-02100 AIR FILTER 1 -

75B 07003-00026 O RING 1 -

75C 74202-02096 1/4 CONNECTION 1 -

75D 07003-00029 O RING 4 -

75E 74202-02097 MALE CONNECTION 1 -

75F 74202-02099 CIRCLIP 1 -

75G 74202-02098 FEMALE CONNECTION 1 -
