Items in bold represent sub-assemblies which can be found on page 19.
6
ENGLISH
ITEM PARNT NO DESCRIPTION QTY REC SPARES ITEM PARNT NO DESCRIPTION QTY REC SPARES
1 74202-02101 HANDLE ASSEMBLY 1 - 41 74202-02048 HEAD SPRING 1 1
2 74202-02004 AIR CYLINDER 1 42 74200-12079 BALL (RUBBER) 1 2
3 74202-02106 AIR PISTON ASSEMBLY 1 43 74202-02065 SCREW M3 X 12 2 2
4 74202-02005 TIE ROD 2 44 74202-02044 AIR TUBE 2 2
5 74202-02002 RUBBER BOOT 1 45 74202-02045 OIL PLUG 1 1
6 74202-02017 AIR TUBE 1 46 74202-02012 SUSPENSION RING 1
7 74202-02007 ROD GUIDE 1 47 74202-02051 TRIGGER SPRING 1 1
8 74202-02018 VALVE SLEEVE 1 48 74202-02067 TRIGGER PIN 1
9 74202-02019 VALVE SLIDER 1 49 74202-02052 AIR SPRING 1 1
10 74202-02014 BEZEL SWITCH 1 50 74202-02071 WASHER 1
11 74202-02013 TRIGGER VALVE 1 51 74202-02072 LIP SEAL 1 1
12 74202-02020 TRIGGER 1 52 74202-02076 WASHER 2 2
13 74202-02021 NOSE CASING 1 53 74202-02077 TIE ROD NUT 2 2
14 74202-02022 CHUCK NUT 1 54 74201-12081 LIP SEAL 1 1
15 74202-02023 MANDREL ADAPTOR 1 55 74202-02086 WASHER 1
16 74202-02024 T JOINT 1 56 74202-02060 O RING 1 1
17 74202-02025 LOCKING NUT 1 57 74202-02066 O RING 2
18A 74202-02006 HYDRAULIC PISTON 1 58 07003-00029 O RING 1
18B 74202-02026 DRIVE PIN 1 59 07003-00134 O RING 1 1
18C 74202-12005 WASHER 1 60 74202-02070 O RING 1 1
19 74202-02010 STROKE ADJUSTER 1 61 74202-02074 O RING 3
20 74202-02107 END CAP ASSEMBLY 1 62 74202-02075 O RING 1 1
21 74202-02105 DISTRIBUTOR ASSEMBLY 1 63 74202-02078 O RING 1 1
22 74202-02030 MANUAL REVERSE SWITCH 1 64 74202-02079 O RING 2 2
23 74202-02031 MANUAL REVERSE SCREW 1 65 74202-02082 O RING 3 3
24 74202-02009 SPOOL VALVE 1 66 07003-00026 O RING 1 1
25 74202-02032 PRESSURE ROD 1 67 74201-12084 O RING 1 1
26 74202-02033 PRESSURE ROD SLEEVE 1 68 07003-00046 O RING 1 1
27 74201-12089 SPRING GUIDE 1 69 07003-00027 O RING 1 1
28 74202-02035 PRESSURE CATCH 1 70 74200-12121 O RING 1 1
29 74202-02036 REGULATOR 1 71 07003-00028 O RING 1 1
30 74202-02037 REGULATOR COVER 1 72 74202-02058 LIP SEAL 1 1
31 74202-02038 REGULATOR LOCK 1 1 73 74202-02039 NOSE ROD 1
32 74202-02056 SPRING 1 1 74 74202-02087 SCREW M3 X 8 3 3
33 74202-02055 LOCKING BEARING 1 1 75 74202-02103 AIR INLET ASSEMBLY 1
34 74202-02054 PRESSURE SPRING 1 76 74202-02089 BASE CAP 1
35 74201-12087 REGULATOR SPRING 1 77 74202-02090 FRONT LABEL 1
36 74202-02080 OIL ROD 1 78 74202-02091 SIDE LABEL 2
37 74202-02041 SLEEVE 1 79 73200-02022 SAFETY LABEL 1
38 74202-02047 NOSE SPRING 1 1 80 74202-02095 LOCKING PIN 1 1
39 74202-02040 CONNECTOR 1 M 1-23 74292-02104 AIR MOTOR ASSEMBLY 1
