24 • ENGLISH
before each use, and clean in accordance with the
instructions if necessary.
Unjamming the motor (On models with this feature)
In case of lengthy stoppages, limescale sediments may cause the
motor to seize. To unjam the motor, turn the drive shaft with a tool.
End-of-season storage
reat the appliance with non-corrosive, non-toxic antifreeze
before storing it away for winter. Put the appliance in a dry
place, protected from frost.
STORAGE AND TRANSPORTATION (Fig. E)
Store the accessories as shown in Fig. E.
Transport the machine as shown in Fig. E.
HOW TO AVOID DAMAGING SURFACES
Warning!
f Using the appliance to wash tyres may damage the
tyre and can be dangerous.
f Never point the high pressure jet straight at the tyre.
f Always use the appliance at the lowest pressure setting
when cleaning in the vicinity of wheels and tyres.
f Never use the “Turbo Lance” for washing any part of
the vehicle.
f For further information refer to section: “Recommended
cleaning procedure”.
PROTECTING THE ENVIRONMENT
Separate collection. This product must not be disposed of
with normal household waste. Should you find one day that
your STANLEY product needs replacement, or if it is of no
further use to you, do not dispose of it with household waste.
Make this product available for separate collection.
Separate collection of used products and
packaging allows materials to be recycled and
used again. Re-use of recycled materials helps
prevent environmental pollution and reduces the
demand for raw materials. Local regulations may
provide for separate collection of electrical products
from the household, at municipal waste sites or by
the retailer when you purchase a new product.
¡Important! To ensure product SAFETY and RELIABILITY,
repairs, maintenance and adjustment (other than those listed in
this manual) should be performed by authorized service centers
or other qualified organizations, always using identical replacement
parts. Unit contains no user service able parts inside.
SERVICE INFORMATION
STANLEY offers a full network of company-owned and
authorized service locations. All STANLEY Service Centers are staffed
with trained personnel to provide customers with efficient and reliable
power tool service. For more information about our authorized service
centers and if you need technical advice, repair, or genuine factory
replacement parts, contact the STANLEY location nearest you.
SPECIFICATIONS SW25
AR, CH 220V~ 50Hz B2C, B2 220V~ 60Hz B3 120V~ 60Hz BR 127V~ 60Hz
Power 2800W 2800W 2400W 2400W
Working flow 8,3 l/min 8,3 l/min 6,8 l/min 6,8 l/min
Max water flow 9,2 l/min 9,2 l/min 7,7 l/min 7,7 l/min
Pressure 14 MPa (140 bar) 14 MPa (140 bar) 14 MPa (140 bar) 14 MPa (140 bar)
Maximum pressure 15 MPa (150 bar) 15 MPa (150 bar) 15 MPa (150 bar) 15 MPa (150 bar)
MAX PSI 2175 2175 2175 2175
T° input 50 ºC 50 ºC 50 ºC 50 ºC
Maximum input pressure 1 MPa 1 MPa 1 MPa 1 MPa
Repulsive force of the gun to
the maximum pressure
23,1 N 23,1 N 19 N 19 N
Motor insulation Class F Class F Class F Class F
Motor protection IPX5 IPX5 IPX5 IPX5
Sound level K=2,5 dB(A):
L
PA
(EN 60704-1) 72 dB(A) 72 dB(A) 72 dB(A) 72 dB(A)
L
WA
(EN 60704-1) 88 dB(A) 88 dB(A) 88 dB(A) 88 dB(A)
Unit vibrations (K = 1 m/s
2
): ‹2,5 m/s ‹2,5 m/s ‹2,5 m/s ‹2,5 m/s
Weight 24,5kg (54lb) 24,5kg (54lb) 21,3kg (47lb) 21,3kg (47lb)
