IFBD-HE0708 BE07 User’s Manual
2-3
2.3 Ambient Conditions
AmbientStorageConditions: StorageTemperature:-20˚C-+70˚C
Storage Humidity: 20% - 90% (Must be no condensation)
AmbientOperatingConditions: OperatingTemperature:0˚C-+55˚C
Operating Humidity: 20% - 80% (Must be no condensation)
2.4 CompatibleSpecications
EMI FCC Part15 Class A
VCCI Class A
EN55022 Class B
2.5 ConnectorSpecications
2.5.1 Network Interface (RJ45)
Manufacturer and Model Number
Hirose Electric Co., Ltd. TM11R-5M2-88-LP
Pin Number
Pin Number Signal Name Direction Remarks
1 TX+ Output
2 TX- Output
3 RX+ Input
4-5 NC -
6 RX- Input
7-8 NC -
I/F card is the standard for direction.
The pin at the right toward the insertion side is pin 1.
