Star DTS27 - Structure; Structure of Energy Meter

Operation Manual of DTS27 Three-phase Energy Meter
5
Functional block diagram
2. Structure
2.1 Structure of energy meter
MCU:
01
LEDs of communication module
02
Sealing screw of communication module
03
Communication module
04
Sealing screw of upper cover
05
Optical port
06
Upper cover
07
Sealing screw of terminal cover
08
Terminal Cover
