StarLine E96, E66
12
Specifications
Parameter Value
Radio exchange protocol Bluetooth Smart
Remote key operating frequency 868,7 - 869,2 MHz
Remote key control range up to 1500 meters
Range of notication to the remote key up to 2000 meters
Interfaces • 2 CAN
• 2 LIN
• 1 universal code bus StarLine Bus
• 1 USB
• 18 recongurable channels:
• 17 outputs of OC (open collector) ОК
0,2А
• 2 outputs 2А
• 3 positive inputs
• 3 negative inputs
• 1 universal input
• a connector for the engine temperature
sensor
• a connector for the valet button
Supply voltage 8-16 V
Operating temperature range from −40 to +85 °С
Overall dimensions of main unit 106х63х17 mm
Weight 63 g
