Starline Roldeck - S-Switch Control Panel

RDCM V03-1015100
4.4 S-Switch control panel
E
F
D
A
B C
ROLDECK
13:24
31
O
C
MENU
G
Function Description
A “Mode” – key By pressing this key for more then 3 seconds,will
direct you in the set-up menu. For example you
can see:
• Information of the controlbox
• Calibrate temperature
• Programming extra remote controls
• Setup time and date
By pressing this key one time short, will set your
pool lights on or off.
B “Open” key By pressing this key the Roldeck will roll up.
C “Close” key By pressing this key the Roldeck will be unrolled.
D Control – “Open” / “Close” Status reading the Roldeck and other functions.
E Time Time indication
F Temperature Water temperature reading (optional)
G Indicator symbols Indicates for example lights or jetstream are on.
With the arrow keys  of  the Roldeck
can be “opened” or “closed”.
By touching one of the three keys when
opening or closing the Roldeck, the
Roldeck stops.
Manual del usuario Starline Roldeck
