Startco SE-105 - RK-105 I Remote Indication Assembly

Startco Engineering Ltd. Page 8
SE-105 Ground-Fault Ground-Check Monitor Rev. 9
Pub. SE-105-M, November 24, 2005.
NOTES:
1. DIMENSIONS IN MILLIMETRES (INCHES).
2. NEMA 1.
FRONT VIEW
GROUND CHECKGROUND CHECK
GROUND FAULTGROUND FAULT
STARTCO
ENGINEERING LTD.
RK-105I
60.0
(2.36)
44.5
(1.75)
(0.30)
(0.40)
7.7
10.0
96.0
(3.78)
76.0
(3.00)
(0.875)
22.25
28.58
(1.125)
1.25"
CONDUIT
KNOCKOUT
1.70" DIA
3.8 (0.15)
DIA
MOUNTING DETAIL
SIDE VIEW
30.0
(1.18)
25.0
(0.98)
CI/RI
+
GI
OUTLINE
FIGURE 8. RK-105I Remote Indication Assembly.
60.2
31.0
47.5
21.0
(2.37)
(1.22)
(1.87)
(0.83)
R
S
1
R
S
2
C
G
I
G
R
I
+
S
W
K1 K2
R
S
1
R
S
2
C
G
I
G
R
I
+
S
W
K1 K2
SW CI/GI +
GI/RI
TB1
INSTALLATION INSTRUCTIONS:
1. REMOVE FOUR LEFTMOST LOWER TERMINAL BLOCK SCREWS.
2. PLACE RK-13 ON TERMINAL BLOCK AND REPLACE SCREWS.
3. MAKE REQUIRED CONNECTIONS TO TERMINAL BLOCK TB1.
SIDE VIEW
RK-13 SHOWN MOUNTED ON SE-105
NOTES:
1. DIMENSIONS IN MILLIMETRES (INCHES).
FIGURE 9. RK-13 Relay Interface Module.
