Startco SE-105 - Zener-Diode Termination Devices; SE-TA6 Termination Assembly

Startco Engineering Ltd. Page 6
SE-105 Ground-Fault Ground-Check Monitor Rev. 9
Pub. SE-105-M, November 24, 2005.
0.25" - 28 UNF
11.4
(0.45)
33.0
(1.30)
GC
G
1N4553B
GGC
69.9
(2.75)
1N5339B
NOTES:
1. DIMENSIONS IN MILLIMETRES
(INCHES).
2. MAY BE IMMERSED IN GLYCOL.
G
FIGURE 4. Zener-Diode Termination Devices.
40.0
(1.57)
19.0
(0.75)
10.5
(0.41)
8.0
(0.31)
51.0
(2.01)
67.0
(2.64)
TAP M4
OR 8-32
MOUNTING DETAIL
NOTES:
1. DIMENSIONS IN MILLIMETRES (INCHES).
2. TERMINAL-BLOCK SCREWS: 6-32 x 0.25.
3. MOUNTING SCREWS: M4 OR 8-32.
4. ENCLOSURE IS ELECTRICALLY CONNECTED
TO TERMINAL G.
5. MAY BE IMMERSED IN GLYCOL.
4.5 (0.18) Ø, C'BORE 10.0 (0.39) Ø
3.2 (0.13) DEEP
67.0
(2.64)
40.0
(1.57)
GC
G
TERMINATION
ASSEMBLY
FRONT
MADE IN SASKATOON, CANADA
STARTCO
ENGINEERING LTD.
SE-TA6
22.2
(0.87)
41.5
(1.63)
SIDE
FIGURE 5. SE-TA6 Termination Assembly.
