Startco SE-105 - RK-102 Remote Indication and Reset; RK-105 Remote Indication-And-Reset Assembly

Startco Engineering Ltd. Page 7
SE-105 Ground-Fault Ground-Check Monitor Rev. 9
Pub. SE-105-M, November 24, 2005.
NOTES:
1. DIMENSIONS IN MILLIMETRES
(INCHES).
2. INDICATES CLEARANCE
REQUIRED.
3. PANEL THICKNESS 1.0 TO 6.0
(0.04 TO 0.24).
4. NEMA 4X.
LEGEND PLATE
30.0
(1.18)
LEGEND
PLATE
22.2 (0.87) DIA
25.0
(0.98)
15.0
(0.59)
22.5
(0.89)
MOUNTING DETAIL
30.0 MINIMUM
(1.18)
40.0 MINIMUM
(1.57)
LED PILOT LIGHTS
36.6
(1.44)
17.3
(0.68)
29.9
(1.17)
43.5
(1.71)
PUSH BUTTON
36.6
(1.44)
14.9
(0.59)
29.9
(1.17)
43.5
(1.71)
FIGURE 6. RK-102 Remote Indication and Reset.
FRONT VIEW
GROUND CHECKGROUND CHECK
GROUND FAULTGROUND FAULT
RESET
STARTCO
ENGINEERING LTD.
RK-105
60.0
(2.36)
44.5
(1.75)
(0.30)
(0.40)
7.7
10.0
96.0
(3.78)
76.0
(3.00)
(0.875)
22.25
28.58
(1.125)
1.25"
CONDUIT
KNOCKOUT
1.70" DIA
3.8 (0.15)
DIA
MOUNTING DETAIL
SIDE VIEW
30.0
(1.18)
25.0
(0.98)
CI/RI
+
GI
SW
OUTLINE
NOTES:
1. DIMENSIONS IN MILLIMETRES (INCHES).
2. NEMA 1.
FIGURE 7. RK-105 Remote Indication-and-Reset Assembly.
