StarTech.com STNDMTV70 - Assemble the TV mount

Instruction manual
16
Assemble the TV mount
1. Slide the crossbars through the top and bottom openings in the support plate.
(gure 7)
gure 7
2. Position the crossbars so that they are centered on the support plate and the holes
on the crossbars are aligned with the holes in the support plate.
3. Insert four of the M6x14 mm screws through the crossbars and into the support
plate. (gure 8)
4. Use a Phillips type screwdriver to tighten the M6x14 mm screws.
gure 8
Crossbar
Support plate
Crossbar
Support plate
M6x14 mm screw
Screwdriver
