Instruction manual
35
7. Hook the multimedia shelf over the screws in the shelf bracket and slide the
multimedia shelf downwards.
8. Insert two M6x14 mm screws into the multimedia shelf and into the shelf bracket.
9. Use a Phillips type screwdriver to tighten all four of the M6x14 mm screws. (gure 25)
gure 25
Multimedia shelf
Shelf bracket
M6x14 mm screw
