Steca StecaGrid 8 000+ 3ph User Manual

14.2 AC cables and line circuit breakers
Inverter AC cable conductor cross-section Line circuit breaker
StecaGrid 8000+ 3ph 5 x 1.5 mm² 3 x B16
5 x 2.5 mm² 3 x B16 or 3 x B25
5 x 4.0 mm² 3 x B16 or 3 x B25
StecaGrid 10 000+ 3ph 5 x 2.5 mm² 3 x B20
5 x 4.0 mm² 3 x B25
Tab. 12: Conductor cross-sections of the AC cables and suitable line circuit breakers
14.3 Table of countries
Details on setting the country are provided in Section 8.8, p. 62.
Note
The requirements for the country-specific grid parameters may change at short notice. Contact the
Steca Customer Service if the parameters specified below no longer correspond to the legally pre-
scribed requirements in your country. See Section Contact, p. 80.
Country
Reconnec-
tion time
Voltage disconnection
values (peak values)
2)
Voltage disconnection
values (average values)
3)
Frequency discon-
nection values
4)
upper lower upper lower upper
8)
lower
Name Display
1)
s % s % s % s % s Hz s Hz s
Germany
5)
4900 Deutschland 60 15.0 0.2 –20.00 0.20 10 600.0 – – 1.5 0.2 –2.5 0.2
Sweden 4600 Sverige 30 15.0 0.2 –15.00 0.20 6 60.0 –10 60.0 1.0 0.5 –3.0 0.5
France 3300 France 30 15.0 0.2 –15.00 0.20 10 600.0 – – 0.2 0.2 –2.5 0.2
Portugal 35100 Portugal 20 15.0 0.2 –15.00 1.50 – – – – 1.0 0.5 –3.0 0.5
Spain 3400 España 180 10.0 0.2 –15.00 0.20 – – – – 1.0 0.2 –1.0 0.2
The Netherlands 3100 Nederland 30 10.0 2.0 –20.00 2.00 – – – – 1.0 2.0 –2.0 2.0
Belgium_1
6)
3200 Belgique 1 30 10.0 0.1 –50.00 0.10 – – –15 1.5 0.5 0.1 –2.5 0.1
Belgium_1 unlimited 3201 Belgique 1 unl 30 10.0 0.1 –50.00 0.10 – – –15 1.5 0.5 0.1 –2.5 0.1
Belgium_2
6)
3202 Belgique 2 30 15.0 0.2 –20.00 0.20 10 600.0 – – 0.5 0.2 –2.5 0.2
Belgium_2 unlimited 3203 Belgique 2 unl 30 15.0 0.2 –20.00 0.20 10 600.0 – – 0.5 0.2 –2.5 0.2
Austria 4300 Österreich 30 15.0 0.2 –20.00 0.20 12 600.0 – – 1.0 0.2 –3.0 0.2
Italy_1 3900 Italia 1 30 20.0 0.1 –20.00 0.20 – – – – 0.3 0.1 –0.3 0.1
Italy_2 3901 Italia 2 30 20.0 0.1 –20.00 0.20 – – – – 1.0 0.1 –1.0 0.1
Italy_3 3902 Italia 3 30 22.0 0.1 –25.00 0.20 – – – – 5.0 0.2 –3.5 0.2
Slovenia 38600 Slovenija 30 15.0 0.2 –15.00 0.20 11 1.5 – – 1.0 0.2 –3.0 0.2
Czech Republic 42000 Česko 30 15.0 0.2 –15.00 0.20 10 600.0 – – 0.5 0.2 –0.5 0.2
Greek Islands 3001 Greece islands 180 15.0 0.5 –20.00 0.50 10 600.0 – – 1.0 0.5 –2.5 0.5
Greek Mainland 3000 Greece continent 180 15.0 0.5 –20.00 0.50 10 600.0 – – 0.5 0.5 –0.5 0.5
Australia
6)
6100 Australia 60 17.0 2.0 –13.00 2.00 – – – – 5.0 2.0 –3.5 2.0
Turkey 9000 Türkiye 30 15.0 0.2 –20.00 0.20 10 600.0 – – 0.2 0.2 –2.5 0.2
Ireland 35300 Éire 30 10.0 0.5 –10.00 0.50 – – – – 0.5 0.5 –2.0 0.5
United Kingdom G83 4400 United Kingdom G83 180 14.7 1.5 –10.00 1.50 – – – – 0.5 0.5 –3.0 0.5
United Kingdom G59 4401 United Kingdom G59 180 15.0 0.5 –20.00
0.50 10 1.0 –13 2.5 0.1 0.5 –2.5 0.5
Switzerland 4100 Suisse 30 15.0 0.2 –20.00 0.20 10 600.0 – – 0.2 0.2 –2.5 0.2
Hungary 3600 Magyarország 30 35.0 0.1 –50.00 0.10 10 2.0 –15 2.0 1.0 0.2 –1.0 0.2
Denmark_unlimited 4500 Danmark unlimited 60 15.0 0.2 –20.00 0.20 10 600.0 – – 1.5 0.2 –2.5 0.2
Denmark
7)
4500 Danmark 60 15.0 0.2 –20.00 0.20 10 600.0 – – 1.5 0.2 –2.5 0.2
EN 50438 50438 EN 50438 20 15.0 0.2 –15.00 1.50 – – – – 1.0 0.5 –3.0 0.5
Bulgaria 3590 Bâlgarija 30 15.0 0.2 –20.00 0.20 10 600.0 – – 0.2 0.2 –2.5 0.2
Mauritius 23000 Mauritius 180 10.0 0.2 –6.00 1.50 6 1.5 – – 1.0 0.5 –3.0 0.5
Tab. 13: Table of countries
1)
Country code and name as shown on the display.
2)
Disconnection values are upper and lower deviations from the peak values of the rated voltage
78
744.378 | 12.13
EN
