16
Connecting diagram:
Menu navigation: (here for the scheme 'Basic' )
OK
Measuring values collector: °C
Operating status storage bottom: °C
+Settings
sola
r
-
p
um
p
Δ:
h
OK OK
sola
r
-
p
um
p
Σ:
h
Parameter storage max. 60°C
Date / Time collector max. 130°C
+Clocks Diff. temp. solar ON 8K
+Service Diff. temp. solar OFF 4K
OK OK + Menu (2 sec.)
+speed control
System selection -intern. heat exchanger
Functions
OK
Links -1storage tank
Extras
OK
Manual operation -1collector
OK
~Basic
choose with OK (2sec.)
{Basic-AH
{Basic-AH-SFH
{Basic-AH-SFH-Ci
{Basic-AH-Ci
{Basic-SFH
{Basic-SFH-Ci
{Basic-R
{Basic-Ci
S7
T3 T4 T5
R2 R3 R4
