12 Technical Data
Operating voltage
230 volts ( ± 15 % ), 50 Hz
Self consumption
≤ 3.0 W
7 inputs
Of which 2 x temperature (Pt1000) or radiation input
and 5 x temperature (Pt1000) or pulse input for calorimetry
4 outputs
R1 as switch output Triac for speed control, switching capacity max. 250 W at 230 V
R2 Triac for speed control, switching capacity max. 480 W at 230 V
R3 Switch relay, switching capacity max. 800 W at 230 V
R4 Switch relay, switching capacity max. 800 W at 230 V
Or R4 voltage-free Remove jumper (activation e.g. of gas heating devices)
Outputs are protected against overcharge and short circuit.
Interfaces
IS bus
Add-on modules, remote data display,
CAN bus converter
Fault signal output Switch relay for safety extra-low voltage
RS232
Serial interface PC/modem for measured data acquisition/remote
data transfer
Display
Graphic-compatible dot matrix display with 122 x 32 pixels, plain
text display
Type of protection
IP 20 / DIN 40050
Ambient temperature allowed
0 to + 45° C
Installation
Wall-mounted
Weight
570 g
Housing
Recyclable, 3-part plastic housing
Dimensions LxWxH (mm)
150 x 215 x 43 mm
Temperature sensors
Pt1000 (4 x included in delivery) 1.5 m silicon cable, temperature range up to 180° C
Batterieladesysteme +
Präzisionselektronik GmbH
Germany
Environmentally friendly
chlorine-free bleached paper
Part number 709.756
Printed in Germany
Status 08/08
Subject to alteration
