Temperature sensor resistance values
Temperature [°C] -30 -20 -10 0 10 20
Resistance [Ω] 882 922 961 1000
1039 1078
Temperature [°C] 30 40 50 60 70 80
Resistance [Ω] 1117 1155 1194 1
232 1
271 1309
Temperature [°C] 90 100 110 120 130
140
Resistance [Ω] 1347 1385 1423 1461
1498 1536
Temperature [°C] 150 160 170 180
Resistance [Ω] 1573 1611 1648 1685
10 Dismantling and disposal
DANGER
Risk of death by electrocution!
Disconnect the controller from the power supply
before dismantling it.
To dismantle the controller, follow the installation
instructions in the reverse order.
Dispose of the controller in accordance with the
local regulations.
