Installation 2.15 Comfort Plus
C006 Output Control Configuration - Configures the output controls of the Comfort Plus system. To
determine the value, check the options desired from the list below. Then, add the numbers from the
“Value” column and enter the sum into this location.
Value Option Selected
2 All 3100 Series Systems.
3 All 4100 Series Systems.
8 Enables compressor control if there is a "COOL" call during a peak (control) time.
32 If it is a peak (control) period and the Comfort Plus receives a cooling call, the com-
pressor will turn off and on in 20 minute intervals (off 20 minutes, on 20 minutes, off
20 minutes, etc.).
128 Interfaces Comfort Plus with a heat pump that has a reversing valve which is energized
for heating.
C007 Charge Factor - This configuration should be set to a value of 30.
C008 through C010 configurations are only applicable if the Comfort Plus system is being used
in conjunction with a heat pump.
C008 Heat Pump Compressor Outdoor Lock-Out Temperature for Off-Peak or Anticipated Peak
Modes - Indicates the outdoor temperature at which the heat pump’s compressor is locked out and not
allowed to operate during an off-peak or anticipated peak period.
C009 Heat Pump Compressor Outdoor Lock-Out Temperature for On-Peak Mode - Indicates the
outdoor temperature at which the heat pump’s compressor is locked out and not allowed to operate
during an on-peak period.
C010 Minimum Discharge Air Temperature - Sets the minimum discharge air temperature the system
targets during a Stage 1 heat call.
C011 Currently not utilized in the 3100/4100 Comfort Plus systems.
C012 Currently not utilized in the 3100/4100 Comfort Plus systems.
C013-C021 Time Clock Module Configuration - These configuration settings are used to configure the peak
control times when utilizing the optional Steffes Time Clock Module. Refer to the installation and
configuration instructions included with the module for more information.
