Appendix A.07 Comfort Plus
Appendix
When ordering parts, please include the system model and serial numbers.
DWG.
REF. DESCRIPTION 4120 4130 4140
NO.
ITEM NO. ITEM NO. ITEM NO.
42 Back Bottom Base Painted Panel 5940582 5940582 5940582
43 Left Side Bottom Painted Panel 5940594 5940594 5940594
44 Left Side Back Painted Panel 5940599 5940530 5940598
45 Core Limit Switch 290D 1012019 1012019 1012019
46 Limit Zone Painted Cover 5940585 5940527 5940591
47 Left Side Top Painted Panel 5940584 5940584 5940584
48 Left Side Core Panel 5940561 5940565 5940560
49 Insulation Blanket Inner 1054130 1054134 1054140
50 Insulation Blanket Outer 1054132 1054136 1054142
51 Back Painted Panel 5940593 5940528 5940592
52 Galvanized Core Panel Back 5940563 5940567 5940562
53 Galvanized Core Panel Top 5940564 5940564 5940564
54 Core Blower Limit Switch 170D 1012009 1012009 1012009
55 Discharge Air Sensor 1041536 1041536 1041536
56 Supply Air Blower Limit Switch 190D 1012026 1012026 1012026
57 Supply Air Blower Wiring Harness 1041514 1041514 1041514
58 Supply Air Blower 1/2 HP 1075 RPM 1040086 1040086 1040086
" Supply Air Blower 3/4 HP 1075 RPM 1040091 1040091 1040091
59 Supply Air Blower Capacitor 1018006 1018006 1018006
60 Plenum Assembly 1022009 1022009 1022009
61 Supply Air Blower Assembly 1/2 HP 1041530 1041530 1041530
" Supply Air Blower Assembly 3/4 HP 1041548 1041548 1041548
62 Terminal Block 6 Position 1016041 1016041 1016041
63 Electrical Panel, Main Body 5940556 5940556 5940556
64 Electrical Panel, Bottom 5940554 5940554 5940554
65 Interface Cable, 18" 1010014 1010014 1010014
66 Interface Cable, 12" 1010012 1010012 1010012
67 Faceplate Label 1159029 1159029 1159029
68 Time Clock Module (optional) 1301014 1301014 1301014
PARTS LIST - 4100 SERIES CONTINUED
