32 CI2 Operation Manual
Appendix
English
Appendix
General Specifications
Specifications and descriptions in this manual are for information purposes only. Steinberg/Yamaha Corp. reserves
the right to change or modify products or specifications at any time without prior notice. Since specifications, equip-
ment or options may not be the same in every locale, please check with your Steinberg/Yamaha dealer.
Jacks
MIC/LINE/HI-Z Jack x1 Combo jack (XLR, 1/4" TS or 1/4" TRS)
MIC/LINE Jack x1 Combo jack (XLR, 1/4" TS or 1/4" TRS)
LINE OUT Jacks (L, R) x2 Phone jacks (1/4" TS or 1/4" TRS)
PHONES Jack x1 Phone jack
FOOT SW Jack x1 Phone jack
USB Connector x1 USB1.1, 44.1/48 kHz, 24 bit
Controls
HI-Z INPUT 1 Button x1
ON: for guitars, etc
OFF: for microphone or synthesizer, etc
MONO Button x1
ON: Input 1, 2 signals function as independent mono chan-
nels.
OFF: Input 1, 2 signals function as a stereo pair.
INPUT 1/2 GAIN Controls x2 GAIN for input 1/2
PHANTOM INPUT 1&2 Button x1
Turns on/off the phantom power for INPUT 1&2. (+48V,
XLR-type only).
MASTER Control x1 Adjusts the signal level sent to the LINE OUT jacks.
PHONES Control x1 Adjusts the signal level sent to the PHONES jack.
MIX Control (INPUT—DAW) x1 Adjusts the signal level between the INPUT and DAW.
LOCK Button x1 Locks the parameter to be edited via the AI KNOB.
AI KNOB x1
Turning: Controls the parameter on Cubase.
Pressing: Opens certain windows in Cubase.
Action Pad Button x1 Uses the Interactive Recording function on Cubase.
Power Supply
USB bus-powered
Dimensions (W x H x D)
W190 x H45.4 x D134.5 mm
Net Weight
720 g
Included Accessories
• Cubase AI DVD-ROM
• TOOLS for CI2 CD-ROM
•USB cable
• Operation Manual
