Appendix
Getting Started
31
ENGLISH DEUTSCH FRANÇAIS ESPAÑOL
Functions
European models
Purchaser/user Information specified in EN55103-1 and EN55103-2.
Inrush current: 2.0 A (MR816 CSX), 2.0 A (MR816 X)
Conforms to environments: E1, E2, E3, E4
Input Channels 1 – 8
Analog Input
MIC Preamp Discrete Class-A MIC preamp (Inverted Darlington Circuitry)
[+48V] button
(Phantom Power switch)
+48 V DC
[PAD] button 0/26 dB
Gain knob 44 dB variable (-60 dB to -16 dB)
Phase Normal/Reversed (controlled via a computer)
High Pass Filter
OFF/80 Hz (-12 dB/oct.)
Controlled via a computer
[HI-Z] switch On/off (for channel 1), Input impedance: 500 kΩ
AD converter 24 bit linear, Enhanced dual-bit delta-sigma conversion
[SIG/PEAK] lamp
-3dB or mode (red), -40db – -3dB (green) (when the clipping point of the signal
is assumed to be 0 dB)
Output Channels 1 – 8
Analog Output
Level Control
Multi Function Encoder knob control (for all the channels 1 – 8)
Software control (for each of the channels 1 – 8)
DA converter 24 bit linear, 128 times oversampling Advanced multi-bit delta/sigma conversion
Headphone jacks
1 and 2
Level Control Multi Function Encoder knob control
Maximum Output Level 25mW (@ 8Ω)/75mW (@ 40Ω)
IEEE1394 jack Audio interface 16-ch input/16-ch output
